Hydrogen Sulfide Detector

Product Description

With firm commitment to quality, we are involved in manufacturing, exporting and supplying a wide assortment of Hydrogen Sulfide Detector. This detector is manufactured by making use of the superior quality basic components under the surveillance of our diligent technical experts with the help of innovative techniques. It is mainly used for measuring H2S concentrations in confined area. Further, this Hydrogen Sulfide Detector is available in varied technical specifications.

This Hydrogen Sulfide Detector is integrated with advanced technology and available for clients at reasonable price. With the help of expert workforce, this product is manufactured using high end technology. It features attributes like unique infrared gas sensor, ratio calculation and display and auto zero setting with air. Owing to the performance oriented design, this product is tested strictly through various parameters. By considering clients requirements, we offer the entire range in various technical specifications to choose from.

Features:

• Unique infrared NDIR gas sensor

• Can measure concentration of other gases

• Air to fuel ratio calculation and display

• Auto zero setting with air

Specifications:

Model	XS-2200
Gas Detected	Hydrogen Sulfide (H2S)
Deletion Principle	Electrochemical cell
Sampling Method	Diffusion
Detection Range (Service Range)	0-30.0ppm (30.1-100ppm)
Resolution	0-35.0ppm: 1ppm 35-100ppm: 5ppm
Indication Accuracy	Within + 1.5ppm + 1digit
Alarm Set Value 1st stage 2nd stage	10.0ppm 15.0ppm
Response Time	30s or less
Display Mode	LCD (Manual backlight)
Alarm Mode	Buzzer sounds, flashing red light, vibrator
Functions	Peak hold, Remaining battery level, memory of peak value, alarm functions except gas alarm (remaining battery level, sensor malfunction, air-adjustment malfunction).
Operating Temperature	-10oC to 40oC, 30-85% RH (non-condensing)
Operating Air Pressure	Air pressure+-10%
Power Source	1 x AAA alkaline dry cell
Battery Life	Up to 5,000 hours (at 20 oC with less than 5ppm)
Dimensions	W65 x D22 x H64mm (excluding protrusions)
Weight	Approx. 75g (including battery)
Standard Accessories	1 x AAA alkaline dry cell, 1 x safety pin adaptor (with fixing screw)

• Under identical measuring conditions.
• Assuming 90% response and operating at 20 + 2DegC.
• Battery life may vary with ambient conditions, conditions of use, storage period, battery manufactures, etc.
• Available with gas calibration kit (optional).

Technical Details

Customizable Hydrogen Sulfide Detection

Our detector tailors its features such as test range, display, and operational method according to specific customer requirements, making it suitable for a variety of industrial applications. Whether you need a unique test material or specific pedestal size, each component is selected to match your needs, prioritizing accuracy and adaptability.


Industrial-Grade Durability and Performance

Constructed with a robust plastic shell and engineered for demanding environments, this detector is built to withstand rigorous industrial conditions. The high-visibility yellow finish ensures easy identification, and the electronic system delivers dependable results for safeguarding your workplace.


Nationwide Distribution and Support

As a widely recognized product offered by leading distributors, exporters, importers, manufacturers, service providers, suppliers, and traders in India, you can expect reliable support and service. Our extensive network ensures you get the right product backed by professional assistance.
